Overview
All users are advised to review the HIMACS sheet information before starting work. Accurate dimension details will help calculate the required number of sheets and reduce material waste on your project. The visible appearance characteristics of each HIMACS sheet should also be considered when discussing the design with the client, as certain colours can influence the quality and aesthetic value of the finished work.
1. Standard dimension
The table below lists the standard dimensions of HIMACS sheets. Please refer to the ‘Remarks’ column for information on the specific HIMACS sheets available to you.
THICKNESS (MM) | WIDTH (MM) | LENGTH (MM) | REMARKS |
|---|---|---|---|
6 | 760 | 2,490 | A |
910 | 2,490 | B | |
1,350 | 3,680 | B | |
1,520 | 3,680 | B | |
9 | 760 | 3,680 | A, B, D, E |
910 | 3,680 | A | |
1,350 | 3,680 | A | |
1,520 | 3,680 | A | |
12 | 760 | 3,680 | C |
910 | 3,680 | D | |
1,350 | 3,680 | D | |
1,520 | 3,680 | D | |
20 | 760 | 3,000 | E |
930 | 3,100 | F |
Note on Availability
Not all colours are available in all sizes and thicknesses.
A. Only available in Solids, Granite, Lucent, Concrete (G554, G555, G556, G557)
B. Only available in Solids, Granite, Concrete (G554, G555, G556, G557)
C. Available in all colours.
D. Only available in Solids, Granite, Concrete (G554, G555, G556, G557)
E. Only available in Solids, Granite, Lucia, Volcanics , Concrete (G554, G555, G556, G557)
F. Only available in Solids, Granite
Additional Notes
Certain colours may not be available in some countries. Please contact your local sales manager or distributor for detailed information.
HIMACS sheets include an additional length and width allowance of up to 10 mm to protect the sheet from damage. Defects within this allowance are not grounds for a claim. Please refer to the HIMACS Quality Inspection document.
Do not join HIMACS sheets with different standard dimensions or from different lot numbers. Please refer to the documents HIMACS Sheet Number and HIMACS Seaming (Bonding).
2. Colour and Texture Descriptions
Collection | Description |
|---|---|
Solids | Pure, single colour without chips or veining. |
Lucent | Translucent solid colour suitable for creating lighting effects. |
Concrete | Modern textured colour inspired by a concrete finish. |
Aurora | Premium trend colour featuring elegant, multicoloured veining, inspired by the dramatic natural phenomenon of the aurora. |
Marmo | Premium colour with bold, random veining, inspired by natural marble. |
Ultra | High-performance colour developed with Ultra Colour Technology, offering enhanced durability and ultra-thermoforming capability. |
Granite, Lucia, Volcanics, Aster | A variety of colours with rich textures inspired by natural granite. |
Gravilla | An enhanced version of Granite, featuring a softer and more detailed tone-on-tone pattern. |
Terrazzo | A modern reinterpretation of traditional terrazzo, featuring large, high-contrast chips for a rugged and robust texture. |
Note
Please consult your local HIMACS manager or distributor, and review a physical sample to experience the actual texture.
3. Colour icons and special notes
Considerations for Fabrication and Installation:
| Some of the dark, heavily pigmented colours of HIMACS may require special care, as they can show scratches, dust, and signs of ordinary wear more readily than lighter or textured colours. For this reason, these colours are not recommended for surfaces subject to high levels of traffic. |
| These colours are suitable for exterior use, offering strong resistance to sunlight (UV). Please refer to the document HIMACS Exterior Wall (Facade) Installation for details on suitability and warranty conditions for each colour. |
| These randomly veined, elegant colours require specific fabrication and installation guidelines. Please refer to the document HIMACS Fabrication for Specific Colours to achieve the best aesthetic results. |
| Lucent colours exhibit a higher level of translucency, which becomes more pronounced when combined with a light source. Please refer to the document HIMACS Fabrication for Specific Colours to achieve optimal lighting effects. |
| Colours marked in this way display a dramatic semi-translucent veining effect when illuminated. Please refer to the document HIMACS Fabrication for Specific Colours to achieve the optimal lighting effect. |
| Some colours feature a glittering or pearlescent effect. These colours require careful fabrication for the best results. Please refer to the document HIMACS Fabrication for Specific Colours. |
| Due to the nature of the pattern, which includes large and high-contrast chips, distribution may be uneven. Specific fabrication and installation guidelines must therefore be followed. |
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Note
For guidance on selecting the ideal colour for your application, please consult your local
HIMACS manager or distributor.
